Camera ảnh nhiệt cầm tay HIKVISION DS-2TP31B-3AUF

– Cảm biến hình ảnh: Uncooled Focal Plane Arrays.

Độ phân giải 160×120.

Temperature accuracy: ±0.5℃.

– Thermographic Range: 30-45℃.

– Chiều cao lắp đặt: 1.5m.

– Khoảng cách khuôn mặt: 1m.

Thông số kỹ thuật

Parameter
Image sensor	Uncooled Focal Plane Arrays
Max. Resolution	160 ×120
Pixel Pitch	17μm
Response waveband	8μm to 14μm
NETD	< 40mK (@ 25 °C,F#=1.0)
Field of View	37.2°×50°
Focal length	3.1 mm
IFOV (mrad)	5.48 mrad
Thermal
Min. Focus Length	≥ 150 mm
Module
Aperture	F 1.1
Monitor	320 ×240 resolution 2.4’’ LCD display
Image Display
Palettes	Black hot, White hot, Rainbow, Ironbow
Rules	3 thermometry points: Max. Temperature; Min. Temperature; Center Temperature
Thermography
Thermographic Range	30°C to 45 °C
Thermographic Accuracy	±0.5 °C
Battery Type	Rechargeable Lithium Battery
Battery
Battery Operating Time	8 hours continuous running
Laser Light	Support (Point to the thermography target)
Functions
Storage	Replaceable memory card (default 8G, support up to 128G storage)
Photo	Thermal image
General
Language	English
Power	3.7 V DC/0.4 A
Power Consumption	Less than 1.2 W
Hardware Interface	Micro USB
Working Temperature	-10 °C to 50 °C (14 °F to 122 °F)
Protection level	IP54
Drop Test Height	2m (6.56 feet)
Dimension	196 mm ×117 mm ×59 mm (7.7 ″ × 4.6 ″ × 2.3 ″)
Weight	Approx. less than 350 g (0.77 lb)
Accessory	Power Adaptor, USB cable, 8GB memory card, User manual, Disk, Wrist Strap
